tms is one kind of low speed high torque radial piston motor with advanced design in disc distribution flow,piston structure,high pressurerating,smooth running at very low speeds,available with different valves,brakes,it is widely applied in mining,crane,geologic drilling,constructionmachinery,etc.
■ characteristics
|
型号
type |
排量displacement(ml/r) |
压力
pressure(mpa) |
扭矩torque
(n.m) |
转速范围speed
range
(r/min) |
最大输出功率max cont
power(kw) |
|
单速
single
speed |
双速double
speed |
尖峰压力
peak
pressure |
连续压力
cont
pressure |
额定扭矩(n.m)
rate torque |
单位理论扭矩(n.m/mpa)theoric torque |
|
tms50-3500 |
3500 |
1750 |
35 |
25 |
13226 |
529 |
0-90 |
110 |
|
tms50-4000 |
4008 |
2004 |
35 |
25 |
15157 |
606 |
0-90 |
110 |
|
tms50-5000 |
4997 |
2499 |
35 |
25 |
18897 |
755 |
0-80 |
110 |
|
tms50-5500 |
5504 |
2752 |
35 |
25 |
20815 |
832 |
0-70 |
110 |
|
tms50-6000 |
6011 |
3006 |
35 |
25 |
22732 |
909 |
0-70 |
110 | |
